ANNEX G: SUNDRIES PAGE 71
BOTTOMING
As for most work under pressure, it is preferable to do this type of bending in
the centre of the press.
Delete the
field.
Delete or leave the Y1 and Y2 fields unprogrammed.
The press makes the descent in the conventional way until the beam stops in
the bottom of the die with the pressure of the current sequence.
The DNC notes that the beam has stopped and the ascent cycle is then
switched on.
ANGLE CORRECTION
It can happen that the angle bent is slightly greater or less than the angle
programmed.
The operator has then the possibility to introduce the real value of the angle
bent. The DNC will correct the Y1 and Y2 axis values in consequence.
This page allows to introduce and display the corrections on the calculated
axis values for the current product and bend.
Call the CORRECTION page by pressing the
key.
The passage to the following or previous bend is made by using the
or
keys.
N 1 CY __
-COR N- -COR P-
90.0°
MES ___._° ___._°
Y1 ___.__ ___.__
Y2 ___.__ ___.__
X ___.__ ___.__
