PAGE 34 USER GUIDE DNC 60 PS
PUNCH / DIE PROGRAMMING
GENERAL EXPLICATIONS
The programming of tools is done by introducing their values and dimen-
sions on the page as represented below.
 Call the PROGRAMMING PUNCH / DIE page (via the main menu).
p Punch angle.
hp
Height of the punch between the lowest part of
the beam and the point of the punch.
rp
Punch radius.
TON/M
Maximum force supported by the punch per
linear meter.
Vd
V width of the die.
d
V angle of the die.
hd
Height of the die from the surface of the table.
rd
Die radius.
TON/M
Maximum force supported by the die per linear
meter.
REF Y
Sum of the hp and hd.
This value is automatically calculated during
programming of pairs. See The tool reference.
SAF X
X Safety distance.
(Not
programmed = half V opening)
a: and b:
Table and die dimensions according to the
drawing displayed on the screen.
