CYBELEC DNC 60 PS User Manual

ANNEX B: THE USER INTERFACE PAGE 23
ANNEX B: THE USER INTERFACE
THE SCREEN
The screen displays the products, tools and machine parameters as well as all
other useful information for programming and machine work.
The keys situated on the front of the DNC are used for selecting the screen
pages and introducing data.
A cursor indicates where the user can intervene.
On all pages, when first displayed the cursor is located on the programmable
field on which it was placed during the last intervention on that page.
The cursor can be moved to the previous or following field by pressing the
or key. Holding down one of the keys produces an auto-repeat
which moves the cursor forward or backward as long as the key is held
down.
Faster Regardless of the cursor position on the page , pressing the
and the
keys simultaneously moves the cursor to the first programmable field
of the page.
THE KEYBOARD
The keyboard is divided into six zones:
 Numerical keyboard
 Screen page selection keys
 Working mode zone
 The commands
 The cursor keys
 The manual mode keys
NUMERICAL KEYBOARD
The numerical keys as well as the and keys are used to intro-
duce numbers or values into the different fields.
