PAGE 74 USER GUIDE DNC 60 PS
THE INTERACTIVE MESSAGES
CASSETTE
Indicates that the "cassette" (internal memory)
- has not been initialized
- is polluted
- has changed the format (e.g. by changing the software
version).
Just "clean" the internal memory by placing the cursor on
the P field, entering 999 and pressing the
key.
COMPLETE
Displayed in
mode when the buffer is full. (No
more space for an additional sequence).
COPIED
Displayed in
mode when a new sequence has been
created at the end of the program using the
key.
DELETED
Displayed in
mode when a product or sequence is
deleted using the
key.
END
Displayed in
or mode, indicates the last se-
quence of the program.
Err - axes
Following error (theoretical trajectory).
Err - FC
Limit switch error.
ERROR
This message is indicated when a calculation is impossi-
ble, or would create out-of-range values.
When security measures are in force (in other words when
an axis is told to move beyond its authorized limits).
This information is followed by a return to
mode
and the cursor positions itself automatically over the field
to be corrected.
ERROR
In the case of a transmission exterior ->DNC, this message
indicates that the data received are not valid, and thus
impossible to read.
EXECUTED
The DNC has made the calculation correctly (corrections,
transformations, etc.).
EXISTS
Indicates that the product or tool number chosen for stor-
age already exists.
FREE
Displayed in
mode when the buffer is empty (no
sequences programmed).
IGNORE
Displayed when the key used cannot (must not) be used at
that time.
INSERTED
Indicates that the insertion has been made correctly.
Jitter
Error caused by the application of simultaneous edges on
