PAGE 76 USER GUIDE DNC 60 PS
ANNEX H: TRANSFER
For transfer to a PC by serial line the DNC 60 must be equipped with the
RS232 option. .
Products The PC must be equipped with the CYBELEC PC1200 software. This unity
allows to create products in the bending software on PC and to transfer them
to the DNC for execution.
Backup The PC must be equipped with the CYBACK storage software.
CYBACK allows to make a backup of the data in the DNC without interven-
tion on the data on the PC's level.
Updating Easy, practical and very rapid, this possibility facilitates in case of necessity
the updating of the DNC software in the FLASH memory.
The PC must be equipped with the updating software.
Call the TRANSFER DNC <
--
> PC page via the main menu.
DNC <-> PC STATUS STOP PA
TRANSFER 11 1 DNC --> PC
2 PC --> DNC
3,4 DATA LINK TEST 1 2
7 FLASH
8 EXT KEYBD
10 ARDIS CONNECTION
11 INTERNAL BACKUP
12 INTERNAL RESTORE
Quantity of free backup memory 93 %
-- RS232 PARAMETERS --
Baud rate 57600 Stop 1.0
Parity odd (1) EVEN (0) _ Bits 8
Who commands ? This page will only be used to initialize the transmission type. It is not pos-
sible to start the transmission from the DNC, this will always be done from
the PC.
TRANSFER Allows to select the type of transmission.
DNC PC Initializes the transmission PC-DNC. Mode 1 or
2 can be selected indifferently.
DATA LINK TEST Selects the test mode of the serial ports.
See the following chapter.
FLASH Prepares the DNC to receive an updating.
EXT KEYBD Puts the DNC in external terminal mode.
See the concerned chapter.
MODEM Not yet available.
CHOICE This field allows to select the objects to be trans-
ferred.
In the case of option 6 PRODUCTS N°, it is
necessary to fill in the last fields of the page with
the numbers of the products to be transferred.
