CYBELEC DNC 60 PS User Manual

ANNEX E: TOOL PROGRAMMING PAGE 33
ANNEX E: TOOL PROGRAMMING
The DNC 60 has several pages which allow consultation of the list of exist-
ing tools, to display them and / or program new ones.
The DNC 60 memory can hold a maximum of 20 punches and 30 dies.
LIST OF PUNCHES
 From the main menu choose option LIST OF PUNCHES.
The system displays the list of punches existing in the memory, with
the number and characteristics of each punch:
LIST p/d 1/ 1
p/d 1/__ __/__ __/__ __/__
PUNCH
p 90° ___° ___° ___°
hp 100.00 ___.__ ___.__ ___.__
rp 1.50 ___.__ ___.__ ___.__
TON/M 100 ___ ___ ___
DIE
Vd ___.__ ___.__ ___.__ ___.__
d ___° ___° ___° ___°
hd ___.__ ___.__ ___.__ ___.__
rd ___.__ ___.__ ___.__ ___.__
TON/M ___ ___ ___ ___
REF Y ___.__ ___.__ ___.__ ___.__
SAF X ___.__ ___.__ ___.__ ___.__
If your DNC contains more than 4 punches, you can call the following page
or pages by pressing
.
List of dies
From the main menu, choose option LIST OF DIES.
The consultation of the list of dies can be done in the same way as explained
for the punches.
