PAGE 30 USER GUIDE DNC 60 PS
CHOICE OF MAIN MENU
1 NEW PRODUCT
Create a new product and display the page sequence,
ready for entering the data.
2 EASY BEND
Access EASY BEND Page
Al
lows for quickly programming a bend and/or stop-
ping production to quickly do another job (bend) with-
out loss or modification of the program in hand.
3 LIST OF PARTS
DNC/CRITERIA
This double page displays the list of parts held in DNC
memory and allows for selectively seeking parts.
4 LIST OF PUNCHES
Displays the list of punches.
5. LIST OF DIES
Displays the list of dies.
6 PUNCH / DIE
PROGR.
From this page, it is possible to recall, program or de-
lete a die or a punch.
7 PRODUCT
PUNCHES / DIES
This page allows to modify, for the product only, the
reference of a tool.
8 PRODUCT STATUS;
L;
Generally called L-alpha page, this page displays and
allows the programming of products in "lengths and
angles" mode.
9 PRODUCT
BENDS;LEGS
Displays the page allowing to program or modify the
bending order.
10 PRODUCT X;
; Y
Displays for each sequence the calculated axis position.
11 PROGR. AXES
ORIGINS
Allows to program the axis position counter.
12 TRANSFER
DNC <-> PC
Allows the global or partial two way transfer of prod-
ucts, tools or machine parameters between the fixed
internal memory and a PC.
13 MACHINE
PARAMETERS
Displays a series of pages which allow to introduce,
display and modify the machine parameters.
14 MACHINE
CONTROLS
Page allowing to control and to modify the state of
certain inputs and outputs (according to the configura-
tion).
