ANNEX I: PRINT OF THE CURRENT SCREEN
The DNC 60 authorizes, if the RS232 port is included, to print the content of a
page displayed on the screen (connector J5).
This allows, through a hardcopy, to retain information regarding the prod-
uct(s), tools or machine parameters.
To be able to send this information to the printer, it is compulsory that you
use a serial printer (RS232).
You have to program the DNC 60 transmission parameters to the printer's re-
quired specifications.
Baud rate: 4800 max.
Bits: 7 or 8
Stop bits: 1, 2 etc.
Parity: 1 or leave blank
Protocol : this field defines how many DNC pages you want to have on
one printer page. After the relevant number the DNC sends a
form feed character.
Example: 1 = 1 DNC page per printer page.
2 = 2 DNC pages per printer page, etc.
BCC: this field defines the left margin in cm.
left margin = 2 + (BCC x 2)
Valid range: 0 (2 space characters) to 9 (20 space characters)
Example: BCC = 4, then 2 + (4 x 2) = 10
TO PRINT FROM THE DNC
 Select the relevant page.
 Simultaneously press the stop
and correction or menu
keys.
