PAGE 72 USER GUIDE DNC 60 PS
COR N This column allows to make a correction for the
current sequence only. (The wording COR N
may possibly not appear according to the ma-
chine configuration, however it concerns always
the fields of the left column).
COR P This column allows to make corrections on the
whole product in one single operation.
Value of the angle programmed in the sequence.
This field is not programmable on this page. It
simply repeats the desired value.
MES Value of the angle measured after bending.
By leaving the field the DNC calculates auto-
matically the correction for Y1-Y2.
According to whether the operator will apply
this correction to the current sequence or to all
the sequences having the same angle, the meas-
ured value is to program in the COR N or COR
P column.
Y1, Y2, X, etc. Direct corrections on the axes.
The following working method is recommended:
Program or call the product.
Pass to semi-automatic mode.
Execute the first bend.
Measure the result.
Enter the measured angle in the COR N or COR P field (see above).
The DNC calculates automatically the corrections to apply in Y1 and
Y2.
If necessary, make the corrections on the gauge axes.
Bend a second product on the first bend, in order to control the cor-
rections.
Pass to the next sequence and proceed in the same way for the follow-
ing sequences.
When all the bends are correct, pass to automatic mode and produce
normally.
Axes Y1-Y2 If the operator wishes to intervene directly on the values of the Y1 and Y2
axes, he has to do it on this page directly in the Y1-Y2 fields, and not in the
sequence page
.
