PAGE 40 USER GUIDE DNC 60 PS
P+
Number of the next product which will be
executed automatically.
If this field is left empty, when the last se-
quence of the product is executed, the program
will return to the first sequence of the current
product.
If it contains a product number, it will be exe-
cuted immediately at the end of the current
product.
This allows to follow on several programs one
after another. Do not forget to program in the
last program the number of the first program in
order to close the loop.
N
Number of the current sequence, whose axe's
values are displayed on the sequence page.
I/mm
Allows to choose the unit of length.
Programmed at 1, the face length values are
expressed in Inches.
Not programmed or programmed with a value
other than 1, the data is displayed in millime-
tres.
CODE
Code name or number (facultative), allowing
to associate supplementary information with
the product number in order to facilitate prod-
uct management and searching.
For the introduction of alphanumerical charac-
ters, see
Alphanumerical characters, page 73.
CAL
Allo
ws automatic compensation of variations
in sheet metal thickness.
For programming this field, refer to chapter
Calibration, page 66.
p/d
Punch and di
e of the current product.
St:
Choice of product material, steel, aluminium or
Al:
stainless steel.
S.S.:
Program 1 in the field next the material used.
If no field is programmed, steel is used by
default.
Th:
Material thickness.
Kg/mm²
(Sigma) Tensile strength.
Lmat
Bending length.
Dev L
Unfolded length of the product calculated by
the system according to DIN 6935 standard.
