D-Link DCS-5220 User Manual

37D-Link DCS-5220 User Manual
Section 3 - Configuration
Enabling UPnP port forwarding allows the Network Camera to open a secondary HTTP port on the router. You have
to add the secondary HTTP port number behind the Network Camera’s public address in order to access the Network
Camera from the Internet. For example, when the HTTP port is set to 80 and the secondary HTTP port is set to 8080,
refer to the list below for the Network Camera’s IP address.
From the Internet In a local area network
http://203.67.124.123:8080 http://192.168.4.160 or
http://192.168.4.160:8080
If the PPPoE settings are incorrectly congured or the Internet access is not working, restore the Network Camera to
factory default settings.

D-Link DCS-5220 Specifications

Operating Environment

operating temperature	0˚ to 40˚C (32˚- 104˚F)
storage temperature	-40˚ to 70˚C (-14˚ - 158˚F)
humidity	Max. 95% RH

Power

external power supply	12V DC 1.5A
power consumption	4.8 Watts

Camera Specifications

cmos sensor	1/4”
minimum illumination	0.5 Lux @ F2.0
viewing angle horizontal	270º
viewing angle vertical	90º

Video and Audio

video resolution at 160x120	Up to 30fps
video resolution at 176x144	Up to 30fps
video resolution at 320x240	Up to 30fps
video resolution at 640x480	Up to 30fps
audio bitrate AAC	16kbps~128kbps
audio bitrate GSM-AMR	4.75kbps~12.2kbps

Weight and Dimensions

width	4.1”
height	4.4”
depth	4.3”
item weight	0.7 lbs
packaging weight	2.9 lbs
