D-Link DCS-5220 User Manual

40D-Link DCS-5220 User Manual
Section 3 - Configuration
The accessibility of the RTSP streaming for the three authentication modes are listed in the following table.
Quick Time
player
Real Player VLC media
player
mpegable
Player
pvPlayer
Disable O O O O O
Basic O O X X X
Digest O X X X X
O indicates that the authentication mode is supported by the RTSP player.
X indicates that the authentication mode is NOT supported by the RTSP player.
Access name for stream 1 / Access name for stream 2 : The access name is used to differentiate the streaming source. When
using a RTSP player to access the Network Camera, and the video mode is set to MPEG-4, use the following RTSP URL command
to request a transmission of streaming data.
rtsp://<ip address>:<rtsp port>/<access name for stream1 or stream2>
For example, when the access name for stream 1 is set to live.sdp, the URL command is : rstp://192.168.5.121/live.sdp
1 : Launch a RTSP player.
2 : Choose File > Open URL. This opens the URL dialog box.
3 : Type the URL command in the text box.
For example:
4 : The live video will be displayed in your player.

D-Link DCS-5220 Specifications

Operating Environment

operating temperature	0˚ to 40˚C (32˚- 104˚F)
storage temperature	-40˚ to 70˚C (-14˚ - 158˚F)
humidity	Max. 95% RH

Power

external power supply	12V DC 1.5A
power consumption	4.8 Watts

Camera Specifications

cmos sensor	1/4”
minimum illumination	0.5 Lux @ F2.0
viewing angle horizontal	270º
viewing angle vertical	90º

Video and Audio

video resolution at 160x120	Up to 30fps
video resolution at 176x144	Up to 30fps
video resolution at 320x240	Up to 30fps
video resolution at 640x480	Up to 30fps
audio bitrate AAC	16kbps~128kbps
audio bitrate GSM-AMR	4.75kbps~12.2kbps

Weight and Dimensions

width	4.1”
height	4.4”
depth	4.3”
item weight	0.7 lbs
packaging weight	2.9 lbs
