D-Link DCS-5220 User Manual

41D-Link DCS-5220 User Manual
Section 3 - Configuration
The port number that you use for RSTP streaming, the default port number is 554. RTP (Real Time Protocol) Port is used
to streaming audio and video while RTCP (Real Time Control Protocol) port is used to monitor QoS of RTP stream.
Note: RTP video port and RTP audio port must be an “even” number. The numbers of RTCP video port and RTCP audio
port must equal to the numbers of RTP video port and RTP audio port, plus one repetitively.
Default port number is 5556.
Default port number is 5557.
You may choose to enable multicast for your camera audio and video streaming so that your cameras (sources) and the
receivers (clients) can establish the connection to send and receive contents.
An IP Multicast group address is used to send and receive content. Sources use this group address as the destination
address while sending their data packets. Receivers use this group address to inform the network that they are interested
in receiving packets sent to that group.
RTSP port:
RTP port for video:
RTCP port for
video:
Multicast group
address:

D-Link DCS-5220 Specifications

Operating Environment

operating temperature	0˚ to 40˚C (32˚- 104˚F)
storage temperature	-40˚ to 70˚C (-14˚ - 158˚F)
humidity	Max. 95% RH

Power

external power supply	12V DC 1.5A
power consumption	4.8 Watts

Camera Specifications

cmos sensor	1/4”
minimum illumination	0.5 Lux @ F2.0
viewing angle horizontal	270º
viewing angle vertical	90º

Video and Audio

video resolution at 160x120	Up to 30fps
video resolution at 176x144	Up to 30fps
video resolution at 320x240	Up to 30fps
video resolution at 640x480	Up to 30fps
audio bitrate AAC	16kbps~128kbps
audio bitrate GSM-AMR	4.75kbps~12.2kbps

Weight and Dimensions

width	4.1”
height	4.4”
depth	4.3”
item weight	0.7 lbs
packaging weight	2.9 lbs
