D-Link DSL-2680 User Manual

44D-Link DSL-2680 User Manual
Chapter 4 - Advanced Setup
Port Forwarding
The Port Forwarding menu allows conguration for remote users access to various services outside of their LAN through a public IP address, such as FTP (File
Transfer Protocol) or HTTPS (Secure Web). After conguring the Router for these features, the Router will redirect these external services to an appropriate server
on the users LAN.
Enter an IP address in the Private IP eld, select a Protocol Type from the drop-
down menu, enter a range of ports in the Public Start Port and Public End Port
elds, and then click the Add/Apply button. Finally, click the Reboot button on the
left panel to let your changes take effect.

D-Link DSL-2680 Specifications

Power

input voltage	100-120V
input current	0.5A
frequency	50-60Hz
output voltage	12V
output current	0.5A

Data Transfer Rates

G.dmt full rate downstream	up to 8 Mbps
G.dmt full rate upstream	up to 1 Mbps
G.lite downstream	up to 1.5 Mbps
G.lite upstream	up to 512 Kbps
G.dmt.bis full rate downstream	up to 12 Mbps
G.dmt.bis full rate upstream	up to 1 Mbps
ADSL2+ full rate downstream	up to 24 Mbps
ADSL2+ full rate upstream	up to 1 Mbps

Wireless Transfer Rates

IEEE 802.11b rates	11, 5.5, 2, 1 Mbps
IEEE 802.11g rates	6, 9, 12, 18, 24, 36, 48, 54 Mbps
IEEE 802.11n rates 20MHz	6.5, 13, 19.5, 26, 39, 52, 58.5, 65 Mbps
IEEE 802.11n rates 40MHz	13.5, 27, 40.5, 54, 81, 108, 121.5, 135 Mbps

Media Interface

ADSL interface	RJ-11 connector
LAN interface	two RJ-45 ports
Ethernet connection type	10/100BASE-T
