D-Link DSL-2680 User Manual

1D-Link DSL-2680 User Manual
Chapter 1 - Overview
Overview
Package Contents
y DSL-2680 Wireless ADSL 2+ Ethernet Router
y Power Adapter
y CD-ROM with User Manual
y One twisted-pair telephone cable used for ADSL connection
y One straight-through Ethernet cable
y Quick Installation Guide
If any of the above items are missing, please contact your reseller.
Note: Using a power supply with a different voltage than the one included with the Router will cause damage and void the warranty for this
product.
System Requirements
y ADSL Internet service
Computer with:
y 200MHz Processor or faster
y 64MB Memory or bigger
y CD or DVD-ROM Drive
y Ethernet Adapter with TCP/IP Protocol Installed
y Internet Explorer v6.0 or later, Mozilla Firefox v1.0 or later, Safari 2.0 or later, Google Chrome 1.0 or later
y Windows, Macintosh, or Linux-based operating system, with an installed Ethernet adapter
Please read and make sure you understand all the prerequisites for proper installation of your new Router. Have all the necessary information and equipment on
hand before beginning the installation.

D-Link DSL-2680 Specifications

Power

input voltage	100-120V
input current	0.5A
frequency	50-60Hz
output voltage	12V
output current	0.5A

Data Transfer Rates

G.dmt full rate downstream	up to 8 Mbps
G.dmt full rate upstream	up to 1 Mbps
G.lite downstream	up to 1.5 Mbps
G.lite upstream	up to 512 Kbps
G.dmt.bis full rate downstream	up to 12 Mbps
G.dmt.bis full rate upstream	up to 1 Mbps
ADSL2+ full rate downstream	up to 24 Mbps
ADSL2+ full rate upstream	up to 1 Mbps

Wireless Transfer Rates

IEEE 802.11b rates	11, 5.5, 2, 1 Mbps
IEEE 802.11g rates	6, 9, 12, 18, 24, 36, 48, 54 Mbps
IEEE 802.11n rates 20MHz	6.5, 13, 19.5, 26, 39, 52, 58.5, 65 Mbps
IEEE 802.11n rates 40MHz	13.5, 27, 40.5, 54, 81, 108, 121.5, 135 Mbps

Media Interface

ADSL interface	RJ-11 connector
LAN interface	two RJ-45 ports
Ethernet connection type	10/100BASE-T
