Section 3 - Conguration
Setup Wizard
WELCOME TO THE DLINK SETUP WIZARD
Follow the on-screen instructions. Click Next to continue.
STEP 1: CHANGE YOUR PASSWORD
Enter a new administrator password which will be used to access your DSL-2740M. Click
Next to continue or Skip if you do not wish to change the password at this time.
STEP 2: SELECT INTERNET CONNECTION TYPE
This step of the wizard allows you to congure your Internet connection type. Select your
Country and Internet Service Provider (ISP) from the drop down list. If you have sucessfully
located your ISP, click Next. Otherwise, select Others and go on.
STEP 2: SELECT INTERNET CONNECTION TYPE
Enter your account’s username and password if prompted. Click Next.
STEP 3: FINISH
Click Finish to apply your settings. Click Back to review or modify settings.
Congratulations, setup is complete.

D-Link DSL-2740M Specifications

Ports & Interfaces

RJ-11 ADSL port	1
RJ-45 Ethernet ports	4
Wireless Interface	IEEE 802.11n/g/b

Wireless Specifications

Wireless Bandwidth Rate IEEE 802.11b	11, 5.5, 2, and 1 Mbps
Wireless Bandwidth Rate IEEE 802.11g	54, 48, 36, 24, 18, 12, 9, and 6 Mbps
Wireless Bandwidth Rate IEEE 802.11n 20 MHz	150, 130, 117, 104, 78, 52, 39, 26, 13 Mbps
Wireless Bandwidth Rate IEEE 802.11n 40 MHz	300, 270, 243, 216, 162, 108, 81, 54, 27 Mbps

Operating Environment

Operating Humidity	0% to 90% non-condensing
Non-Operating Humidity	5% to 95% non-condensing
Operating Temperature	0 to 40 °C (32 to 104 °F)
Non-Operating Temperature	-20 to 65 °C (-4 to 149 °F)

Power

Input Voltage	100~240 V AC (±20%), 50/60 Hz
Output Voltage	12 V DC
Output Current	0.5 A

Weight and Dimensions

Dimensions	160 x 120 x 25 mm (6.30 x 4.72 x 0.98 inches)
Weight	205 grams (7.2 ounces)
