Section 3 - Conguration
Inbound Filter
INBOUND IP FILTERInbound Filter
ADVANCED
Click Inbound Filter on the navigation menu to congure the Inbound Filter. The Inbound
Filter allows you to place ltering rules on a per IP basis. Using this tool you may restrict
access to or block trac from a specic remote IP address or range.
The currently dened Inbound Filter rules are listed here. Click Remove to remove a dened
rule.
ACTIVE INBOUND FILTER
Filter Name: Enter a name for this Inbound Filter.
Protocol: Select TCP, UDP, or ICMP from the dropdown menu.
Source IP address: Enter the source IP address.
Source Subnet
Mask:
Enter the source subnet mask.
Source Port: Enter the source port.
Destination IP
address:
Enter the destination IP address.
Destination Subnet
Mask:
Enter the destination subnet mask.
Destination Port: Enter the destination port.
Click the Add/Apply button to add your Inbound IP Filter Rule.
ADD INBOUND IP FILTER

D-Link DSL-2740M Specifications

Ports & Interfaces

RJ-11 ADSL port	1
RJ-45 Ethernet ports	4
Wireless Interface	IEEE 802.11n/g/b

Wireless Specifications

Wireless Bandwidth Rate IEEE 802.11b	11, 5.5, 2, and 1 Mbps
Wireless Bandwidth Rate IEEE 802.11g	54, 48, 36, 24, 18, 12, 9, and 6 Mbps
Wireless Bandwidth Rate IEEE 802.11n 20 MHz	150, 130, 117, 104, 78, 52, 39, 26, 13 Mbps
Wireless Bandwidth Rate IEEE 802.11n 40 MHz	300, 270, 243, 216, 162, 108, 81, 54, 27 Mbps

Operating Environment

Operating Humidity	0% to 90% non-condensing
Non-Operating Humidity	5% to 95% non-condensing
Operating Temperature	0 to 40 °C (32 to 104 °F)
Non-Operating Temperature	-20 to 65 °C (-4 to 149 °F)

Power

Input Voltage	100~240 V AC (±20%), 50/60 Hz
Output Voltage	12 V DC
Output Current	0.5 A

Weight and Dimensions

Dimensions	160 x 120 x 25 mm (6.30 x 4.72 x 0.98 inches)
Weight	205 grams (7.2 ounces)
