D-Link DSL-2740M User Manual

66D-Link DSL-2740M User Manual
Section 3 - Conguration
PASSWORDPassword
MAINTENANCE
Password
The Password section enables you to manage the router password. You should change
the default admin password to secure your network. Ensure that you remember the new
password or write it down and keep it in a safe and separate location for future reference.
If you forget the password, you will need to reset the device to the factory default settings
and all conguration settings of the device will be lost.
Current Password: Enter the current password.
New Password: Enter the new password.
Conrm Password: Re-enter the new password.
Click Apply Settings to have your changes take eect.
SET PASSWORD OPTIONAL

D-Link DSL-2740M Specifications

Ports & Interfaces

RJ-11 ADSL port	1
RJ-45 Ethernet ports	4
Wireless Interface	IEEE 802.11n/g/b

Wireless Specifications

Wireless Bandwidth Rate IEEE 802.11b	11, 5.5, 2, and 1 Mbps
Wireless Bandwidth Rate IEEE 802.11g	54, 48, 36, 24, 18, 12, 9, and 6 Mbps
Wireless Bandwidth Rate IEEE 802.11n 20 MHz	150, 130, 117, 104, 78, 52, 39, 26, 13 Mbps
Wireless Bandwidth Rate IEEE 802.11n 40 MHz	300, 270, 243, 216, 162, 108, 81, 54, 27 Mbps

Operating Environment

Operating Humidity	0% to 90% non-condensing
Non-Operating Humidity	5% to 95% non-condensing
Operating Temperature	0 to 40 °C (32 to 104 °F)
Non-Operating Temperature	-20 to 65 °C (-4 to 149 °F)

Power

Input Voltage	100~240 V AC (±20%), 50/60 Hz
Output Voltage	12 V DC
Output Current	0.5 A

Weight and Dimensions

Dimensions	160 x 120 x 25 mm (6.30 x 4.72 x 0.98 inches)
Weight	205 grams (7.2 ounces)
