Section 3 - Conguration
Firewall & DMZ
FIREWALL & DMZFirewall & DMZ
ADVANCED
This page allows you to manually congure the router’s rewall & DMZ settings. Since some
applications are not compatible with NAT, the device supports the use of a DMZ IP address
for a single host on the LAN. This IP address is not protected by NAT and it is visible on the
Internet with the correct type of software. Note that any client PC in the DMZ is exposed
to various types of security risks. If you use DMZ, take measures (such as client-based virus
protection) to protect the remaining client PCs on your LAN from possible contamination
through DMZ.
Enable DMZ: Check to enable or disable DMZ functionality.
DMZ Host IP
Address:
Enter an IP address to be included in the DMZ or use the << button
to select a device connected to the router.
Click Apply Settings to have your changes take eect.
DMZ HOST
Enable Firewall: Check this box to enable or disable the rewall.
FIREWALL SETTINGS

D-Link DSL-2740M Specifications

Ports & Interfaces

RJ-11 ADSL port	1
RJ-45 Ethernet ports	4
Wireless Interface	IEEE 802.11n/g/b

Wireless Specifications

Wireless Bandwidth Rate IEEE 802.11b	11, 5.5, 2, and 1 Mbps
Wireless Bandwidth Rate IEEE 802.11g	54, 48, 36, 24, 18, 12, 9, and 6 Mbps
Wireless Bandwidth Rate IEEE 802.11n 20 MHz	150, 130, 117, 104, 78, 52, 39, 26, 13 Mbps
Wireless Bandwidth Rate IEEE 802.11n 40 MHz	300, 270, 243, 216, 162, 108, 81, 54, 27 Mbps

Operating Environment

Operating Humidity	0% to 90% non-condensing
Non-Operating Humidity	5% to 95% non-condensing
Operating Temperature	0 to 40 °C (32 to 104 °F)
Non-Operating Temperature	-20 to 65 °C (-4 to 149 °F)

Power

Input Voltage	100~240 V AC (±20%), 50/60 Hz
Output Voltage	12 V DC
Output Current	0.5 A

Weight and Dimensions

Dimensions	160 x 120 x 25 mm (6.30 x 4.72 x 0.98 inches)
Weight	205 grams (7.2 ounces)
