D-Link DSL-2740M User Manual

68D-Link DSL-2740M User Manual
Section 3 - Conguration
Firmware Update
UPDATEFirmware Update
MAINTENANCE
You can upgrade the rmware of the access point here. Please check the D-Link support
website for rmware updates at http://support.dlink.com. You can download rmware
upgrades to your hard drive from this site. Make sure the rmware you want to use is on
the local hard drive of your computer.
Current Firmware
Version:
This eld displays information about the current rmware.
Current Firmware
Date:
This eld displays the date of the current rmware.
FIRMWARE INFORMATION
Click the Backup Now button to save the current conguration.
Upload: Click Browse to locate the rmware le required.
Click Update Firmware to upload and install the selected rmware.
FIRMWARE UPDATE

D-Link DSL-2740M Specifications

Ports & Interfaces

RJ-11 ADSL port	1
RJ-45 Ethernet ports	4
Wireless Interface	IEEE 802.11n/g/b

Wireless Specifications

Wireless Bandwidth Rate IEEE 802.11b	11, 5.5, 2, and 1 Mbps
Wireless Bandwidth Rate IEEE 802.11g	54, 48, 36, 24, 18, 12, 9, and 6 Mbps
Wireless Bandwidth Rate IEEE 802.11n 20 MHz	150, 130, 117, 104, 78, 52, 39, 26, 13 Mbps
Wireless Bandwidth Rate IEEE 802.11n 40 MHz	300, 270, 243, 216, 162, 108, 81, 54, 27 Mbps

Operating Environment

Operating Humidity	0% to 90% non-condensing
Non-Operating Humidity	5% to 95% non-condensing
Operating Temperature	0 to 40 °C (32 to 104 °F)
Non-Operating Temperature	-20 to 65 °C (-4 to 149 °F)

Power

Input Voltage	100~240 V AC (±20%), 50/60 Hz
Output Voltage	12 V DC
Output Current	0.5 A

Weight and Dimensions

Dimensions	160 x 120 x 25 mm (6.30 x 4.72 x 0.98 inches)
Weight	205 grams (7.2 ounces)
