D-Link DSL-2790U User Manual

96D-Link DSL-2790U Wireless N300 ADSL2+ Modem Router User Manual
Section 4 - Conguration
System Log
You can set the levels to log and display by choosing a Log Level and Display Level from
the respective drop-down menus. All events above or equal to the selected level will be
logged/displayed.
By default, the router saves the logs locally. If you want to send the logs to a remote server,
under Mode select Remote and enter the Server IP Address and Server UDP Port below.
Click Apply when you are done, or Cancel to discard your changes. Click View System Log
to view the log.
This table shows the system log for the device. Select Enable Log to switch on the router’s logging function.

D-Link DSL-2790U Specifications

Ports & interfaces

RJ-11 ADSL port	1
RJ-45 Ethernet ports	4 x 10/100BASE-TX
USB port	1 x USB 2.0

Power

Input voltage	100~240 V (±20%)
Input frequency	50~60 Hz
Output voltage	DC 12 V
Output current	1 A

Operating Environment

Operating temperature	0 to 40 °C (32 to 104 °F)
Non-operating temperature	-20 to 65 °C (-4 to 149 °F)
Operating humidity	0% - 90% non-condensing
Non-operating humidity	5% - 95% non-condensing

Weight and Dimensions

Dimensions	68 x 42 x 51 mm (2.68 x 1.65 x 2 inches)
Weight	113.4 grams (4 ounces)
