D-Link DSL-2790U User Manual

117D-Link DSL-2790U Wireless N300 ADSL2+ Modem Router User Manual
Section 6 - Connecting To Your Wireless Network
Windows® 10
When connecting to the DSL-2790U wirelessly for the rst time, you will need to input the wireless network name (SSID)
and Wi-Fi password (security key) of the device you are connecting to. If your product has a Wi-Fi conguration card,
you can nd the default network name and Wi-Fi password here. Otherwise refer to the product label for the default
Wi-Fi network SSID and password, or enter the Wi-Fi credentials set during the product conguration.
To join an existing network, locate the wireless network icon in the taskbar, next to the
time display and click on it.
Clicking on this icon will display a list of wireless networks which are within range of
your computer. Select the desired network by clicking on the SSID.
Wireless Icon

D-Link DSL-2790U Specifications

Ports & interfaces

RJ-11 ADSL port	1
RJ-45 Ethernet ports	4 x 10/100BASE-TX
USB port	1 x USB 2.0

Power

Input voltage	100~240 V (±20%)
Input frequency	50~60 Hz
Output voltage	DC 12 V
Output current	1 A

Operating Environment

Operating temperature	0 to 40 °C (32 to 104 °F)
Non-operating temperature	-20 to 65 °C (-4 to 149 °F)
Operating humidity	0% - 90% non-condensing
Non-operating humidity	5% - 95% non-condensing

Weight and Dimensions

Dimensions	68 x 42 x 51 mm (2.68 x 1.65 x 2 inches)
Weight	113.4 grams (4 ounces)
