D-Link DSL-2790U User Manual

118D-Link DSL-2790U Wireless N300 ADSL2+ Modem Router User Manual
Section 6 - Connecting To Your Wireless Network
To connect to the SSID, click Connect.
To automatically connect with the router when your device next detects the SSID, click
the Connect Automatically check box.
You will then be prompted to enter the Wi-Fi password (network security key) for the
wireless network. Enter the password into the box and click Next to connect to the
network. Your computer will now automatically connect to this wireless network when
it is detected.

D-Link DSL-2790U Specifications

Ports & interfaces

RJ-11 ADSL port	1
RJ-45 Ethernet ports	4 x 10/100BASE-TX
USB port	1 x USB 2.0

Power

Input voltage	100~240 V (±20%)
Input frequency	50~60 Hz
Output voltage	DC 12 V
Output current	1 A

Operating Environment

Operating temperature	0 to 40 °C (32 to 104 °F)
Non-operating temperature	-20 to 65 °C (-4 to 149 °F)
Operating humidity	0% - 90% non-condensing
Non-operating humidity	5% - 95% non-condensing

Weight and Dimensions

Dimensions	68 x 42 x 51 mm (2.68 x 1.65 x 2 inches)
Weight	113.4 grams (4 ounces)
