D-Link DSL-2790U User Manual

89D-Link DSL-2790U Wireless N300 ADSL2+ Modem Router User Manual
Section 4 - Conguration
System
This page allows you to reboot the device, backup your settings, or restore settings either from a le or to their default values.
SYSTEM  REBOOT
Reboot: Click this button to reboot the device.
SYSTEM  BACKUP SETTINGS
SYSTEM  UPDATE SETTINGS
RESTORE ROUTER SETTINGS TO THE FACTORY DEFAULTS.
Backup Settings: Click this button to save the current router configuration settings to a
file on the hard disk of the computer you are using. You will see a file
dialog, where you can select a location and file name for the settings.
Update Settings: To restore a saved conguration, use the Browse... button to nd the
previously saved conguration le. Then, click the Update Settings
button to transfer those settings to the device.
Restore Default
Settings:
Click this button to restore all configuration settings back to the
settings that were in effect at the time the device was shipped
from the factory. Any settings that have not been saved will be lost,
including any rules that you have created.
Warning: Do not turn o your device or press the Reset button while
an operation in this page is in progress.

D-Link DSL-2790U Specifications

Ports & interfaces

RJ-11 ADSL port	1
RJ-45 Ethernet ports	4 x 10/100BASE-TX
USB port	1 x USB 2.0

Power

Input voltage	100~240 V (±20%)
Input frequency	50~60 Hz
Output voltage	DC 12 V
Output current	1 A

Operating Environment

Operating temperature	0 to 40 °C (32 to 104 °F)
Non-operating temperature	-20 to 65 °C (-4 to 149 °F)
Operating humidity	0% - 90% non-condensing
Non-operating humidity	5% - 95% non-condensing

Weight and Dimensions

Dimensions	68 x 42 x 51 mm (2.68 x 1.65 x 2 inches)
Weight	113.4 grams (4 ounces)
