D-Link DSL-2790U User Manual

43D-Link DSL-2790U Wireless N300 ADSL2+ Modem Router User Manual
Section 4 - Conguration
IPv6 Local Network
This section enables you to specify various IPv6 settings.
Interface Address: Use this option to specify a static IPv6 Address.
STATIC LAN IPV6 ADDRESS CONFIGURATION
Enable RADVD: Enable or disable the Router Advertisement Daemon.
Enable ULA Prefix
Advertisement
Select whether to enable ULA Prex advertisement. If selected, choose
to either Randomly Generate the ULA Prex or Statically Congure
the ULA Prex by inputting the Prex, Preferred Life Time in hours,
and Valid Life Time in hours.
Enable MLD
Snooping
Select to enable Multicast Listener Discovery.
Click Save/Apply when you are done.
SITE PREFIX CONFIGURATION
Enable DHCPv6
Server:
Enable or disable the DHCPv6 server function.
LAN Address
Config Mode:
Select either stateless (host requests) or stateful (server provisions)
LAN IPv6 addressing.
Start/End
Interface ID:
Enter the range of IP addresses the DHCPv6 server can issue from.
Leased Time: The lease time determines the period that the host retains the
assigned IP addresses before the IP addresses change.
STATIC LAN IPV6 ADDRESS CONFIGURATION

D-Link DSL-2790U Specifications

Ports & interfaces

RJ-11 ADSL port	1
RJ-45 Ethernet ports	4 x 10/100BASE-TX
USB port	1 x USB 2.0

Power

Input voltage	100~240 V (±20%)
Input frequency	50~60 Hz
Output voltage	DC 12 V
Output current	1 A

Operating Environment

Operating temperature	0 to 40 °C (32 to 104 °F)
Non-operating temperature	-20 to 65 °C (-4 to 149 °F)
Operating humidity	0% - 90% non-condensing
Non-operating humidity	5% - 95% non-condensing

Weight and Dimensions

Dimensions	68 x 42 x 51 mm (2.68 x 1.65 x 2 inches)
Weight	113.4 grams (4 ounces)
