D-Link DSL-2790U User Manual

53D-Link DSL-2790U Wireless N300 ADSL2+ Modem Router User Manual
Section 4 - Conguration
Security Settings
This page allows you to manually congure the router’s wireless security settings. The page will change depending on the
selected authentication type.
WIRELESS SSID
WIRELESS SECURITY MODE
Network
Authentication:
Select the desired security type. The remaining settings on the page will
change depending on the type you select. Fill out these settings as required.
Select SSID: Select your wireless SSID.
WPS SETUP
Enable WPS: If you want to enable Wi-Fi Protected Setup (WPS), select Enable from the
drop-down menu.
Add Client: Select the desired WPS connection method, and click Add Enrollee to add
a new device using WPS. See Add Wireless Device with WPS on page 36
for more details.
Set WPS
AP Mode:
Select the desired WPS AP mode.
Device PIN: If applicable, enter the WPS PIN.
Click Apply when you are done.

D-Link DSL-2790U Specifications

Ports & interfaces

RJ-11 ADSL port	1
RJ-45 Ethernet ports	4 x 10/100BASE-TX
USB port	1 x USB 2.0

Power

Input voltage	100~240 V (±20%)
Input frequency	50~60 Hz
Output voltage	DC 12 V
Output current	1 A

Operating Environment

Operating temperature	0 to 40 °C (32 to 104 °F)
Non-operating temperature	-20 to 65 °C (-4 to 149 °F)
Operating humidity	0% - 90% non-condensing
Non-operating humidity	5% - 95% non-condensing

Weight and Dimensions

Dimensions	68 x 42 x 51 mm (2.68 x 1.65 x 2 inches)
Weight	113.4 grams (4 ounces)
