94D-Link DSL-2790U Wireless N300 ADSL2+ Modem Router User Manual
Section 4 - Conguration
IP Address
ACCESS CONTROL  IP ADDRESSES
Enable Access
Control Mode:
Check to enable access to local management services.
Add: Pressing this button will make the IP Address dialog box appear.
Delete: Check the check box next to an IP address and press the delete button
to remove an IP from the Access Control List.
Warning: If the last IP Address is Deleted from the Access Control List
and still have Access Control enabled, you will be unable to access
the web conguration utility and will need to reset the router.
IP ADDRESSES
IP Address: Enter a desired IP Address to add to the Access Control List.
From this page you can limit access to the router management services to the following list of IP addresses.
Click Apply to add the IP Address to the Access Control List.
