D-Link DSL-2790U User Manual

18D-Link DSL-2790U Wireless N300 ADSL2+ Modem Router User Manual
Section 3 - Getting Started
This step of the wizard allows you to congure your Internet connection type.
If you have an DSL connection, select DSL. If you have a cable or NBN Fiber
connection and are connecting via the WAN port, select ETH WAN.
Step 3: Setup Internet Connection
If you selected Dynamic IP or Bridged, click Next to continue.
If you selected ETH WAN, select and congure the Internet Protocol used by
your ISP: Dynamic IP, Static IP, PPPoE, or Bridged.
If you selected DSL, choose your Country and Internet Service Provider (ISP)
from the drop down menu. The necessary settings will automatically populate.
If you cannot nd your country or ISP, select Others. You will need to enter
the data provided by your ISP manually. Select the Internet Protocol used by
your ISP: Dynamic IP, Static IP, PPPoE, PPPoA, or Bridged. Also select the
Connection Type, and input the VPI and VCI settings.

D-Link DSL-2790U Specifications

Ports & interfaces

RJ-11 ADSL port	1
RJ-45 Ethernet ports	4 x 10/100BASE-TX
USB port	1 x USB 2.0

Power

Input voltage	100~240 V (±20%)
Input frequency	50~60 Hz
Output voltage	DC 12 V
Output current	1 A

Operating Environment

Operating temperature	0 to 40 °C (32 to 104 °F)
Non-operating temperature	-20 to 65 °C (-4 to 149 °F)
Operating humidity	0% - 90% non-condensing
Non-operating humidity	5% - 95% non-condensing

Weight and Dimensions

Dimensions	68 x 42 x 51 mm (2.68 x 1.65 x 2 inches)
Weight	113.4 grams (4 ounces)
