D-Link DSL-2790U User Manual

36D-Link DSL-2790U Wireless N300 ADSL2+ Modem Router User Manual
Section 4 - Conguration
If you clicked Add Wireless Device with WPS, the opening screen of the Wi-Fi
Protected Setup (WPS) wizard will be displayed.
To connect a WPS client, select Auto.
If you select Manual, you will see a summary of your current wireless security
settings. Clients will need to input these settings manually if they wish to
connect to your wireless network.
Click Next to continue.
Add Wireless Device with WPS
If you selected Auto, then if WPS is not already enabled you will be prompted
to enable it. Click Yes to enable WPS.
Choose whether you want to connect via Personal Identication Number (PIN)
or Push Button Conguration (PBC).
If you selected PIN, simply enter your PIN of your wireless device.
Click Connect to proceed to the next step.
Press the button on your wireless client device within the indicated time period
and wait for the connection to be established.

D-Link DSL-2790U Specifications

Ports & interfaces

RJ-11 ADSL port	1
RJ-45 Ethernet ports	4 x 10/100BASE-TX
USB port	1 x USB 2.0

Power

Input voltage	100~240 V (±20%)
Input frequency	50~60 Hz
Output voltage	DC 12 V
Output current	1 A

Operating Environment

Operating temperature	0 to 40 °C (32 to 104 °F)
Non-operating temperature	-20 to 65 °C (-4 to 149 °F)
Operating humidity	0% - 90% non-condensing
Non-operating humidity	5% - 95% non-condensing

Weight and Dimensions

Dimensions	68 x 42 x 51 mm (2.68 x 1.65 x 2 inches)
Weight	113.4 grams (4 ounces)
