D-Link DSL-2790U User Manual

42D-Link DSL-2790U Wireless N300 ADSL2+ Modem Router User Manual
Section 4 - Conguration
CONNECTED CLIENT LIST
This table lists each DHCP client, including its hostname, MAC address, IP address, and
expiration time.
DHCP RESERVATIONS LIST
A list of DHCP reservations is displayed. Click Remove Entries to delete the selected
reservation(s) and Add Entries to bring up the Add DHCP Reservation panel.
IP Address: Enter the IP address you want to assign to the computer or device.
This IP address must be within the DHCP IP address range.
MAC Address: Enter the MAC address of the computer or device. Click Copy Your
PC’s MAC Address to copy the MAC address of the computer you
are currently using into the MAC address field.
ADD DHCP RESERVATIONS OPTIONAL
Click Apply when you are done.

D-Link DSL-2790U Specifications

Ports & interfaces

RJ-11 ADSL port	1
RJ-45 Ethernet ports	4 x 10/100BASE-TX
USB port	1 x USB 2.0

Power

Input voltage	100~240 V (±20%)
Input frequency	50~60 Hz
Output voltage	DC 12 V
Output current	1 A

Operating Environment

Operating temperature	0 to 40 °C (32 to 104 °F)
Non-operating temperature	-20 to 65 °C (-4 to 149 °F)
Operating humidity	0% - 90% non-condensing
Non-operating humidity	5% - 95% non-condensing

Weight and Dimensions

Dimensions	68 x 42 x 51 mm (2.68 x 1.65 x 2 inches)
Weight	113.4 grams (4 ounces)
