D-Link DSL-2790U User Manual

27D-Link DSL-2790U Wireless N300 ADSL2+ Modem Router User Manual
Section 4 - Conguration
Enable NAT: Check this to enable the router to use NAT to assign IP addresses
for your devices.
Enable Firewall: Check to enable the firewall.
Enable IGMP
Multicast:
Check to enable IGMP Multicast.
Enable MLD
Proxy:
Check to enable the MLD proxy.
Service Name: Enter the service name.
NETWORK ADDRESS TRANSLATION SETTINGS
WAN IP SETTINGS
If you selected MAC Encapsulation Routing (MER), enter your IPv4 and/or IPv6 details
and proceed to the Network Address Translation Settings.
Click Next to continue.

D-Link DSL-2790U Specifications

Ports & interfaces

RJ-11 ADSL port	1
RJ-45 Ethernet ports	4 x 10/100BASE-TX
USB port	1 x USB 2.0

Power

Input voltage	100~240 V (±20%)
Input frequency	50~60 Hz
Output voltage	DC 12 V
Output current	1 A

Operating Environment

Operating temperature	0 to 40 °C (32 to 104 °F)
Non-operating temperature	-20 to 65 °C (-4 to 149 °F)
Operating humidity	0% - 90% non-condensing
Non-operating humidity	5% - 95% non-condensing

Weight and Dimensions

Dimensions	68 x 42 x 51 mm (2.68 x 1.65 x 2 inches)
Weight	113.4 grams (4 ounces)
