D-Link DSL-2790U User Manual

55D-Link DSL-2790U Wireless N300 ADSL2+ Modem Router User Manual
Section 4 - Conguration
WAN
Connection:
Select the interface to use with the rule.
Select a
Service:
Select an service for a preset application or enter a name in Custom
Server.
Schedule: Select a schedule or choose Always.
Server
IP Address:
Enter an IP address to appoint the corresponding client to receive
forwarded packets.
External Port
Start/End:
Enter the external port(s).
Protocol: Select TCP or UDP.
Internal Port
Start/End:
Enter the internal port(s).
LAN
Loopback:
Check the box to enable the LAN loopback feature.
PORT TRIGGERING
Click Apply when you are done.

D-Link DSL-2790U Specifications

Ports & interfaces

RJ-11 ADSL port	1
RJ-45 Ethernet ports	4 x 10/100BASE-TX
USB port	1 x USB 2.0

Power

Input voltage	100~240 V (±20%)
Input frequency	50~60 Hz
Output voltage	DC 12 V
Output current	1 A

Operating Environment

Operating temperature	0 to 40 °C (32 to 104 °F)
Non-operating temperature	-20 to 65 °C (-4 to 149 °F)
Operating humidity	0% - 90% non-condensing
Non-operating humidity	5% - 95% non-condensing

Weight and Dimensions

Dimensions	68 x 42 x 51 mm (2.68 x 1.65 x 2 inches)
Weight	113.4 grams (4 ounces)
