D-Link DWR-921 User Manual

DWR-921 4G LTE Router
User Manual
Configuring via Web-based Interface
Parameter Description
NATv6
If the switch is moved to the right, the network address translation
function for IPv6 is enabled. Do not disable the function unless your
ISP requires this.
The switch is displayed when the IPv6 or Dual value is selected
from the Type drop-down list in the Modem Settings section.
Ping
If the switch is moved to the right, the router responds to ping
requests from the external network through this connection. For
security reasons, it is recommended to disable this function.
Figure 87. The page for creating a new Mobile Internet connection. The Modem Settings section.
Parameter Description
Modem Settings
MODEM/SIM CARD
SELECTION
Click the button in order to assign the connection to the SIM card of
the built-in LTE modem.
Mode
The value of the field specifies the type of the network to which the
router connects. Leave the Auto value to let the router connect
automatically to an available type of network, or select a needed
value from the drop-down list.
APN An access point name.
Without authorization
Move the switch to the right if your operator does not require
authorization.
Page 101 of 255

D-Link DWR-921 Specifications

General

VPN support	L2TP/PPTP/IPSEC
Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi band	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	150 Mbit/s
Ethernet LAN (RJ-45) ports	4
DHCP client	-
Antennas quantity	2
Security algorithms	128-bit WEP, 64-bit WEP, WPA, WPA2
Certification	CE, Wi-Fi
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Product color	Black, White
LED indicators	3G, LAN, Power, WAN, WLAN

Weight and Dimensions

Depth	111.5 mm
Width	190 mm
Height	23.5 mm
Weight	500 g
