D-Link G530 - Page 37

32D-Link G530 User Manual
Section 3 - Conguration
Advanced Settings... - Dynamic IP
Address Mode: Select Static IP if the following information has been provided
by your ISP: IP address, MTU, and DNS server addresses. In most
cases, select Dynamic IP.
IP Address: When Static IP is selected as the address mode, the column
for IP address will appear. Enter the IP address provided by
your ISP.
Service Name: Enter the ISP service name (optional)
Primary DNS Server: Enter the primary DNS server IP address assigned by your ISP.
Secondary DNS Server:
Enter the secondary DNS server IP address assigned by your
ISP.
MTU: Maximum Transmission Unit (1280~1500)- you may need to
change the MTU for optimal performance with your ISP. The
default is 1500.
MAC Address Clone: The default MAC address is set to the Internet port’s physical
interface MAC address on the router. You can replace the
Internet port’s MAC address with the MAC address of a
connected client.
