xStack® DES-3200 Series Layer 2 Ethernet Managed Switch CLI Reference Manual
13
1
show scheduling
Used to displ
ay the currently configured traffic scheduling on the Switch.
Purpose
sho
w scheduling
Syntax
This
command is used to display the current traffic scheduling
mechanisms in use on the Switch.
Description
Non
e.
Parameters
Non
e.
Restrictions
Example usage:
To display the current scheduling configuration:
DES-3200-28:4#show scheduling
Command: show scheduling
QOS Output Scheduling
Class ID Weight
--------- -------------
Class-0 1
Class-1 2
Class-2 4
Class-3 8
DES-3200-28:4#
config scheduling_mechanism
Used to co
nfigure the scheduling mechanism for the QoS function
Purpose
config
scheduling_mechanism [strict | weight_fair]
Syntax
This
command is used to select between a weight fair and a strict mechanism for
emptying the priority classes of service of the QoS function. The Switch contains four
hardware priority classes of service. Incoming packets must be mapped to one of
these four hardware priority classes of service. This command is used to specify the
rotation by which these four hardware priority classes of service are emptied.
Description
The Switch’s default is to empty the four priority classes of service in order from the
highest priority class of service (queue 3) to the lowest priority class of service
(queue 0). Each queue will transmit all of the packets in its buffer before allowing the
next lower priority class of service to transmit its packets. Lower classes of service
will be pre-empted from emptying its queue if a packet is received on a higher class
of service. The packet that was received on the higher class of service will transmit
its packet before allowing the lower class to resume clearing its queue.
stri
ct – Entering the strict parameter indicates that the highest class of service is the
first to be processed. That is, the highest class of service should finish emptying
before lower ones begin.
Parameters
weight_fair – Entering the weight fair parameter indicates that the priority classes of
service will empty packets in a fair weighted order. That is to say that they will be
emptied in an even distribution.
Only Administrator-level users
can issue this command.
Restrictions
