xStack® DES-3200 Series Layer 2 Ethernet Managed Switch CLI Reference Manual
22
9
24
SAFEGUARD ENGINE COMMANDS
Periodically, malicious hosts on the network will attack the Switch by utilizing packet flooding (ARP Storm) or other methods.
These attacks may increase the CPU utilization beyond its capability. To alleviate this problem, the Safeguard Engine function
was added to the Switch’s software.
The Safeguard Engine can help the overall operability of the Switch by minimizing the workload of the Switch while the attack is
ongoing, thus making it capable to forward essential packets over its network in a limited bandwidth. When the Switch either (a)
receives too many packets to process or (b) exerts too much memory, it will enter an Exhausted mode. When in this mode, the
Switch will perform the following tasks to minimize the CPU usage:
It will limit bandwidth of receiving ARP packets.
It will limit the bandwidth of IP packets received by the Switch.
IP packets may also be limited by the Switch by configuring only certain IP addresses to be accepted. This method can be
accomplished through the create trusted_host explained in the previous section. Once the user configures these acceptable IP
addresses, other packets containing different IP addresses will be dropped by the Switch, thus limiting the bandwidth of IP packets
The Safeguard Engine commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the
following table.
Command Parameters
config safeguard_engine {state [enable | disable] | utilization {rising <value 20-100> | falling <value
20-100>} (1) | trap_log [enable | disable] | mode [strict | fuzzy]} (1)
show safeguard_engine
Each command is listed, in detail, in the following sections.
config safeguard_engine
Used to co
nfigure ARP storm control for system.
Purpose
{state [enable | disable] | utilization {risi
ng <value 20-100> | falling <value 20-
100>} (1)| trap_log [enable | disable] | mode [strict | fuzzy]} (1)
Syntax
This
command is used to configure Safeguard Engine to minimize the effects
of an ARP storm.
Description
state [enabl
e | disable] – Select the running state of the Safeguard Engine
function as enable or disable.
Parameters
cpu_utilization – Select this option to trigger the Safeguard Engine function
to enable based on the following determinates:
rising <value 20-100> The user can set a percentage value of the rising
CPU utilization which will trigger the Safeguard Engine function. Once the
CPU utilization rises to this percentage, the Safeguard Engine mechanism
will initiate.
falling <value 20-100> The user can set a percentage value of the falling
CPU utilization which will trigger the Safeguard Engine function to cease.
Once the CPU utilization falls to this percentage, the Safeguard Engine
mechanism will shut down.
trap_log [enable | disable] – Choose whether to enable or disable the
sending of messages to the device’s SNMP agent and switch log once the
Safeguard Engine has been activated by a high CPU utilization rate.
mode [strict | fuzzy] – Toggle between strict and fuzzy mode.
strict If selected, this function will stop accepting all ARP packets not
intended for the Switch, and will stop receiving all unnecessary broadcast IP
