xStack® DES-3200 Series Layer 2 Ethernet Managed Switch CLI Reference Manual
3
2
USING THE CONSOLE CLI
The Switch supports a console management interface that allows the user to connect to the Switch’s management agent via a serial
port and a terminal or a computer running a terminal emulation program. The console can also be used over the network using the
TCP/IP Telnet protocol. The console program can be used to configure the Switch to use an SNMP-based network management
application over the network.
This chapter describes how to use the console interface to access the Switch, change its settings, and monitor its operation.
Note:
Switch configuration settings are saved to non-volatile RAM using the save command. The current
configuration will then be retained in the Switch’s NV-RAM, and reloaded when the Switch is rebooted. If
the Switch is rebooted without using the save command, the last configuration saved to NV-RAM will be
loaded.
Connecting to the Switch
The cons
ole interface is used by connecting the Switch to a VT100-compatible terminal or a computer running an ordinary
terminal emulator program (e.g., the HyperTerminal program included with the Windows operating system) using an RS-232C
serial cable. Your terminal parameters will need to be set to:
 VT-100 compatible
 9600 baud
 8 data bits
 No parity
 One stop bit
 No flow control
Users can also access the same functions over a Telnet interface. Once users have set an IP address for your Switch, users can use
a Telnet program (in VT-100 compatible terminal mode) to access and control the Switch. All of the screens are identical, whether
accessed from the console port or from a Telnet interface.
After the Switch reboots and users have logged in, the console looks like this:
DES-3200-28 Fast Ethernet Switch
Command Line Interface
Firmware: Build 1.10.B014
Copyright(C) 2009 D-Link Corporation. All rights reserved.
UserName:
PassWord:
Figure 2 - 1. Initial Console Screen after logging in
Commands are entered at the command prompt, DES-3200-28:4#.
There are a number of helpful features included in the CLI. Entering the ? command will display a list of all of the top-level
commands.
