xStack® DES-3200 Series Layer 2 Ethernet Managed Switch CLI Reference Manual
14
3
DES-3200-28:4#config mirror port 1 add source ports 2-7 both
Command: config mirror port 1 add source ports 2-7 both
Success.
DES-3200-28:4#
Example usage:
To delete the mirroring ports:
DES-3200-28:4#config mirror port 1 delete source ports 2-4 both
Command: config mirror 1 delete source ports 2-4 both
Success.
DES-3200-28:4#
enable mirror
Used to ena
ble a previously entered port mirroring configuration.
Purpose
enabl
e mirror
Syntax
This
command, combined with the disable mirror command below,
allows the user to enter a port mirroring configuration into the Switch,
and then turn the port mirroring on and off without having to modify
the port mirroring configuration.
Description
Non
e.
Parameters
Only Administrator-level users
can issue this command.
Restrictions
Example usage:
To enable mirroring configurations:
DES-3200-28:4#enable mirror
Command: enable mirror
Success.
DES-3200-28:4#
disable mirror
Used to disab
le a previously entered port mirroring configuration.
Purpose
disa
ble mirror
Syntax
This
command, combined with the enable mirror command above,
allows the user to enter a port mirroring configuration into the Switch,
and then turn the port mirroring on and off without having to modify
the port mirroring configuration.
Description
Non
e.
Parameters
Only Administrator-level users
can issue this command.
Restrictions
Example usage:

D-Link xStack DES-3200 Series Specifications

General

Managed	Yes
Layer	Layer 2
MAC Address Table Size	8K
Quality of Service (QoS)	802.1p
Security Features	ACL, 802.1X, Port Security
Jumbo Frame Support	Up to 9KB
Dimensions	Varies by model
Weight	Varies by model
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.1Q, IEEE 802.1p
Forwarding Rate	13.1 Mpps (48-port)
