xStack® DES-3200 Series Layer 2 Ethernet Managed Switch CLI Reference Manual
21
8
config access_profile
specified for all access profiles.
Only Administrator-level users
can issue this command.
Restrictions
Example usage:
To configure the access profile with the profile ID of 1 to filter frames on port 7 that have IP addresses in the range between
10.42.73.0 to 10.42.73.255:
DES-3200-28:4# config access_profile profile_id 1 add access_id 1 ip source
_
ip 10.42.73.1
port 7 deny
Command: config access
_
profile profile
_
id 1 add access
_
id 1 ip source
_
ip 10.42.73.1 port 7
deny
Success.
DES-3200-28:4#
show access_profile
Used to displ
ay the currently configured access profiles on the Switch.
Purpose
sho
w access_profile {profile_id <value 1-512>}
Syntax
This
command is used to display the currently configured access profiles.
Description
profile_i
d <value 1-512> – Specify the profile id to display only the access rules
configuration for a single profile ID. The user may enter a profile ID number
between 1 and 512.
Parameters
Non
e.
Restrictions
Example usage:
To display all of the currently configured access profiles on the Switch:

D-Link xStack DES-3200 Series Specifications

General

Managed	Yes
Layer	Layer 2
MAC Address Table Size	8K
Quality of Service (QoS)	802.1p
Security Features	ACL, 802.1X, Port Security
Jumbo Frame Support	Up to 9KB
Dimensions	Varies by model
Weight	Varies by model
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.1Q, IEEE 802.1p
Forwarding Rate	13.1 Mpps (48-port)
