xStack® DES-3200 Series Layer 2 Ethernet Managed Switch CLI Reference Manual
22
1
create cpu access_profile
address.
profile_id <value 1-3>  Enter an integer between 1 and 3 that is used to identify the CPU access
profile to be created with this command.
Only Administrator-level users
can issue this command.
Restrictions
Example usage:
To create a CPU access profile:
DES-3200-28:4# create cpu access
_
profile profile
_
id 1 ip vlan source
_
ip
_
mask 20.0.0.0
destination_ip_mask 10.0.0.0 dscp icmp type code
Command: create cpu access_profile profile_id 1 ip vlan source_ip_mask 20.0.0.0
destination_ip_mask 10.0.0.0 dscp icmp type code
Success.
DES-3200-28:4#
delete cpu access_profile
Used to delet
e a previously created CPU access profile.
Purpose
delete cpu a
ccess_profile profile_id <value 1-3>
Syntax
This
command is used to delete a previously created CPU access profile.
Description
Parameters
profile_id <value 1-3>  Enter an integer between 1 and 3 that is used to identify
the CPU access profile to be deleted with this command. This value is assigned to
the access profile when it is created with the create cpu access_profile command.
Only Administrator-level users
can issue this command.
Restrictions
Example usage:
To delete the CPU access profile with a profile ID of 1:
DES-3200-28:4#delete cpu access_profile profile_id 1
Command: delete cpu access_profile profile_id 1
Success.
DES-3200-28:4#
config cpu access_profile
Used to co
nfigure a CPU access profile used for CPU Interface Filtering and to define
specific values that will be used to by the Switch to determine if a given packet should be
forwarded or filtered. Masks entered using the create cpu access_profile command will be
combined, using a logical AND operational method, with the values the Switch finds in the
specified frame header fields. Specific values for the rules are entered using the config
cpu access_profile command, below.
Purpose
config
cpu access_profile profile_id <value 1-3> [add access_id <value 1-5>[ethernet {vlan
Syntax

D-Link xStack DES-3200 Series Specifications

General

Managed	Yes
Layer	Layer 2
MAC Address Table Size	8K
Quality of Service (QoS)	802.1p
Security Features	ACL, 802.1X, Port Security
Jumbo Frame Support	Up to 9KB
Dimensions	Varies by model
Weight	Varies by model
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.1Q, IEEE 802.1p
Forwarding Rate	13.1 Mpps (48-port)
