xStack® DES-3200 Series Layer 2 Ethernet Managed Switch CLI Reference Manual
40
5
show dot1v_protocol_group
Used to displ
ay the protocols defined in a protocol group.
Purpose
sho
w dot1v_protocol_group {[group_id <int 1-16> | group_name
<name 32>]}
Syntax
This
command is used to display the protocols defined in protocol
groups.
Description
grou
p_id – Specifies the group ID to be displayed. If a group ID is not
specified, all configured protocol groups will be displayed.
Parameters
group_name – The name of the protocol group.
Non
e.
Restrictions
Example usage:
To display the protocol group ID 1:
DES-3200-28:4# show dot1v_protocol_group group_id 1
Command: show dot1v_protocol_group group_id 1
Protocol Group ID Protocol Group Name Frame Type Protocol Value
----------------- -------------------------------- -------------- --------------
1 General_Group EthernetII 86dd
1 General_Group IEEE802.3 SNAP 86dd
Total Entries: 1
DES-3200-28:4#
