xStack® DES-3200 Series Layer 2 Ethernet Managed Switch CLI Reference Manual
46
8
Example usage:
To display the CFM packet CCM counters:
DES-3200-28:4# show cfm pkt_cnt ccm
Command: show cfm pkt_cnt ccm
CCM RX counters:
XCON = Cross-connect CCMs
Error = Error CCMs
Normal = Normal CCMs
MEP Name VID Port Level Direction XCON Error Normal
----------- ---- ----- ----- --------- ---------- ---------- ----------
mep1 1 1 2 inward 9 8 100
mep2 1 2 2 inward 9 8 100
mep3 1 3 2 inward 9 8 100
-----------------------------------------
Total: 27 24 300
clear cfm pkt_cnt
This
command is used to clear the CFM packet’s RX/TX counters.
Purpose
c
lear cfm pkt_cnt { [ ports <portlist> { [ rx | tx ] } | [ rx | tx ] | ccm ] }
Syntax
CFM packet counters will
be cleared.
Description
ports
<portlist> - The ports which require need the counters clearing. If not specified, all
ports will be cleared.
Parameters
{[rx | tx]} - Clear RX or TX counters. If none is specified, both of them are cleared.
[rx | tx] - Clear only RX or TX counters.
ccm – Clear only CCM RX counters.
Only Administrator-level users
can issue this command.
Restrictions
Example usage:
To clear all CFM packet counters:
DES-3200-28F:4# clear cfm pkt_cnt
Command: clear cfm pkt_cnt
Success.
DES-3200-28F:4#

D-Link xStack DES-3200 Series Specifications

General

Managed	Yes
Layer	Layer 2
MAC Address Table Size	8K
Quality of Service (QoS)	802.1p
Security Features	ACL, 802.1X, Port Security
Jumbo Frame Support	Up to 9KB
Dimensions	Varies by model
Weight	Varies by model
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.1Q, IEEE 802.1p
Forwarding Rate	13.1 Mpps (48-port)
