D-Link xStack DES-3200 Series User Manual

xStack® DES-3200 Series Layer 2 Ethernet Managed Switch CLI Reference Manual
47
2
DES-3200-28F:4# config ethernet
_
oam ports 1 link
_
monitor error
_
symbol threshold 2 window 1000
notify_state enable
Commands: config ethernet
_
oam ports 1 link
_
monitor error
_
symbol threshold 2 window 1000
notify_state enable
Success
DES-3200-28F:4#
config ethernet_oam ports (link monitor error frame)
Used to co
nfigure Ethernet OAM link monitoring error frame configuration for ports.
Purpose
config eth
ernet_oam ports [<portlist> | all ] link_monitor error_frame { threshold <number> |
window < milliseconds 1000-60000> | notify_state [enable | disable ] } (1)
Syntax
The co
mmand used to configure Ethernet OAM link monitoring error frames for ports.
Description
Link monitoring function provides a mechanism to detect and indicate link faults under a variety
of conditions. OAM monitors the counts of the number of frame errors as well as the number of
coding symbol errors. When the number of frame errors is equal to or greater than the
specified threshold in a period and the event notification state is enabled, it generates an error
frame event to notify the remote OAM peer.
<po
rtlist> - Specifies a range of ports to be configured. Use all to specify all ports.
Parameters
threshold - Specify the number of frame errors in the period that must be equal to or greater
than in order for the event to be generated. The default value is 1 frame error.
window - The range is 1000 to 60000 ms. The default value is 1000ms.
notify_state - Specify to enable or disable event notification. The default state is enable.
Only Administrator-level users
can issue this command.
Restrictions
Example usage
To configure the error frame threshold to 2 and period to 1000 ms for port 1:
DES-3200-28F:4# config ethernet
_
oam ports 1 link
_
monitor error
_
frame threshold 2 window 1000
notify_state enable
Commands: config ethernet
_
oam ports 1 link
_
monitor error
_
frame threshold 2 window 1000
notify_state enable
Success
DES-3200-28F:4#

D-Link xStack DES-3200 Series Specifications

General

Managed	Yes
Layer	Layer 2
MAC Address Table Size	8K
Quality of Service (QoS)	802.1p
Security Features	ACL, 802.1X, Port Security
Jumbo Frame Support	Up to 9KB
Dimensions	Varies by model
Weight	Varies by model
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.1Q, IEEE 802.1p
Forwarding Rate	13.1 Mpps (48-port)
