xStack® DES-3200 Series Layer 2 Ethernet Managed Switch CLI Reference Manual
51
0
Example usage:
To configure a NLB multicast MAC forwarding database entry:
DES-3200-28F:4# config nlb multicast_fdb default 03-bf-01-01-01-01 add 1-5
Command: config nlb multicast_fdb default 03-bf-01-01-01-01 add 1-5
Success.
DES-3200-28F:4#
show nlb fdb
Used to displ
ay all configured NLB FDB entries.
Purpose
sho
w nlb fdb
Syntax
This
command will display all NLB FDB entries that have been configured.
Description
Non
e.
Parameters
Non
e.
Restrictions
Example usage:
To display the NLB forwarding table for all NLB FDB entries:
DES-3200-28F:4# show nlb fdb
Command: show nlb fdb
MAC Address VLAN ID Egress Ports
----------------- ---------- ----------------------------------
02-bf-01-01-01-01 - 1-5, 26, 26
02-bf-01-01-01-02 - 1-5, 26, 26
03-bf-01-01-01-01 100 1-5, 26, 26
03-bf-01-01-01-01 1 1-5, 26, 26
Total Entries : 4
DES-3200-28F :4#

D-Link xStack DES-3200 Series Specifications

General

Managed	Yes
Layer	Layer 2
MAC Address Table Size	8K
Quality of Service (QoS)	802.1p
Security Features	ACL, 802.1X, Port Security
Jumbo Frame Support	Up to 9KB
Dimensions	Varies by model
Weight	Varies by model
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.1Q, IEEE 802.1p
Forwarding Rate	13.1 Mpps (48-port)
