D-Link xStack DES-3200 Series User Manual

xStack® DES-3200 Series Layer 2 Ethernet Managed Switch CLI Reference Manual
52
0
Physical and Environmental
Power Consumption
DES-3200-10: 12.7W
DES-3200-18: 13.2W
DES-3200-26: 13.8W
DES-3200-28: 18.4W
DES-3200-28F: 46.7W
Internal Power Supply
DES-3200-10/DES-3200-18: 34W AC Input: 100~240 VAC, 12V/2A, 5V/2A, 50~60Hz
DES-3200-26: 24W AC Input: 100~240 VAC, 12V/2A, 50~60Hz
DES-3200-28: 40W AC Input: 100~240 VAC, 12V/3.3A, 50~60Hz
DES-3200-28F: 60W AC Input: 100~240 VAC, 12V/5A, 50~60Hz
DC Fans
DES-3200-10/DES-3200-18/DES-3200-26/DES-3200-28: None
DES-3200-28F: One fan
Operating Temperature
0 - 40°C
Storage Temperature
-40 - 70°C
Humidity
5 - 95% non-condensing
Dimensions
DES-3200-10/18: 228.5 (W) x 180(D) x 44(H) mm
DES-3200-26/28/28F: 441(W) x 207(D) x 44(H) mm
Weight
DES-3200-10: 1.4553kg
DES-3200-18: 1.5022kg
DES-3200-26: 2.28kg
DES-3200-28: 2.40kg
DES-3200-28F: 2.68kg
EMI
CE Class A, FCC Class A, C-Tick, VCCI
Safety
CB Report, UL
Performance
Transmission Method
Store-and-forward
Packet Buffer
384 KB per device
Packet Filtering/
148.810 pps (100M port)
Forwarding Rate
1,488,100 pps (1Gbps port)
MAC Address Learning
Automatic update. Supports 8K MAC address
Priority Queues
4 Priority Queues per port
Forwarding Table Age Time
Max age: 10-1000000 seconds. Default = 300.

D-Link xStack DES-3200 Series Specifications

General

Managed	Yes
Layer	Layer 2
MAC Address Table Size	8K
Quality of Service (QoS)	802.1p
Security Features	ACL, 802.1X, Port Security
Jumbo Frame Support	Up to 9KB
Dimensions	Varies by model
Weight	Varies by model
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.1Q, IEEE 802.1p
Forwarding Rate	13.1 Mpps (48-port)
