Move the bearing cap with hand, and
release and reassemble it if no move-
ment is detected.
3.3.17. Relief valve
•
Assemble the relief valve.
3.3.18. Oil pump and oil pipe
•
Install a dowel pin in the No.7 bearing
cap, then assemble the oil pump with
specified torque.
•
Assemble the oil suction pipe with the
delivery pipe, then install the bracket
on the bearing cap.
3.3.19. Oil pan
•
Mount gasket and put the oil pan
thereon.
•
Place stiffeners and tighten bolts.
•
Align the bolt holes with gasket holes
to prevent damage to the gasket and
tighten to specified torque.
- 85 -
REASSEMBLY
