Local Configurations 151
Select the check box to enable the function. When an alarm event
occurs, the video output port outputs the settings configured in
Main Menu > DISPLAY > TOUR.
Not all models support this function.
Select the check box to activate a buzzer noise at the Device.
Select the check box to enable the Device to record a local alarm
log.
Select to enable audio broadcast/voice prompts in response to a
motion detection event.
Select the check box to enable the white light alarm of the camera.
Select the check box to enable the sound alarm of the camera.
Table 5-39
Click Apply to save the settings. Step 3
Click Default to restore the default setting.
Click Copy, in the Copy dialog box, select the additional channel(s) that you want
to copy the motion detection settings to, and then click Apply.
Click Test to test the settings.
Setting the Motion Detection Region
Next to Region, click Setting. Step 1
The region setting screen is displayed.
Point to the middle top of the interface.
Step 2
The setting interface is displayed. See Figure 5-122.
Figure 5-122
Configure the regions settings. You can configure totally four regions. Step 3
Select one region, for example, click . 1)
Drag on the screen to select the region that you want to detect. 2)
The selected area shows the color that represents the region.
Configure the parameters. 3)
Enter a name for the region.
Every region of every channel has an individual sensitivity value.
The bigger the value is, the easier the alarms can be activated.
