Dahua L Series

User's Manual
151
Procedure
Step 1 Select
Main Menu
>
CAMERA
>
Overlay
>
Overlay
.
Step 2 Configure parameters.
Table 4-14 Video overlay parameters
Parameter Description
Channel Select a channel.
Time Title
Select
Time Title
, and the time tile will be displayed in live view
and playback.
Drag time title to the target place and click
Apply
.
Channel Title
Select
Channel Title
, and the channel tile will be displayed in live
view and playback.
Drag channel title to the target place and click
Apply
.
Custom Title
You can custom title to be overlaid on the screen. Click
Setting
to
set the information such as font size, title content and text
alignment, and then click
OK
.
Default Set as device default configuration.
Copy to
Click
Copy to
to copy the settings to other channels.
Step 3 Click
Apply
.
4.2.5.2 Privacy Masking
You can set the privacy masking area on the screen to guarantee the privacy of the area.
Procedure
Step 1 Select
Main Menu
>
CAMERA
>
Overlay
>
Privacy Masking
.
