User's Manual
340
Figure 4-225
4.11.8 PPPoE
Background Information
PPPoE is another way for the Device to access the network. You can establish network connection by
configuring PPPoE settings to give the Device a dynamic IP address in the WAN. To use this function,
firstly you need to obtain the user name and password from the Internet Service Provider.
Procedure
Step 1 Select
Main Menu
>
NETWORK
>
PPPoE
.
The
PPPoE
interface is displayed. See Figure 4-226.
Figure 4-226
Step 2 Enable the PPPoE function.
Step 3 In the
User Name
box and
Password
box, enter the user name and password accordingly
provided by the Internet Service Provider.
Step 4 Click
Apply
to complete the settings.
The system pops up a message to indicate the successfully saved. The IP address appears
on the PPPoE interface. You can use this IP address to access the Device.
