Dahua L Series

User's Manual
6
The figure is for reference only. The actual product shall prevail.
Figure 2-3 Front panel
Table 2-2 Icons
Icon Name Function
HDD HDD status indicator light
The blue light is on when the HDD is
malfunction.
NET
Network status indicator
light
The blue light is on when the network
connection is abnormal.
POWER Power status indicator light
The blue light is on when the power
connection is OK.
USB port
Connect to peripheral USB storage device,
mouse and etc.
2.1.3 NVR52-4KS2/NVR52-8P-4KS2/NVR52-16P-4KS2/NVR42-
4KS2/NVR42-P-4KS2/NVR42-8P-4KS2/NVR42-16P-4KS2/NVR42-
4KS2/L/NVR42-P-4KS2/L/NVR42-8P-4KS2/L/NVR42-16P-
4KS2/L/NVR5224-24P-4KS2/NVR54-4KS2/NVR54-16P-4KS2/NVR44-
4KS2/NVR44-16P-4KS2/NVR44-4KS2/L/NVR44-16P-
4KS2/L/NVR5424-24P-4KS2/NVR58-4KS2/NVR58-16P-4KS2/NVR48-
4KS2/NVR48-16P-4KS2/NVR48-4KS2/L/NVR48-16P-4KS2/L/NVR22-
4KS2/NVR22-P-4KS2/NVR22-8P-4KS2/NVR52-8P-4KS2E/NVR52-
16P-4KS2E/NVR54-16P-4KS2E/NVR58-16P-4KS2E Series
The figure is for reference only. The actual product shall prevail.
The NVR52-4KS2/NVR52-8P-4KS2/NVR52-16P-4KS2/NVR42-4KS2/NVR42-P-4KS2/NVR42-8P-
4KS2/NVR42-16P-4KS2/NVR42-4KS2/L/NVR42-P-4KS2/L/NVR42-8P-4KS2/L/NVR42-16P-
4KS2/LNVR5224-24P-4KS2/NVR22-4KS2/NVR22-P-4KS2/NVR22-8P-4KS2/NVR52-8P-4KS2E/NVR52-
16P-4KS2E series front panel is shown as below.
